In short: Inconel® 625 (IN625, UNS N06625) is a solid-solution-strengthened nickel-chromium superalloy with molybdenum and niobium. It combines outstanding corrosion and oxidation resistance with good weldability and is used for chemical, marine, energy and exhaust applications.
Typical applications
- Chemical process equipment and heat exchangers
- Marine and offshore components
- Exhaust and combustion system parts
- Aerospace ducting
Reference properties of printed parts
| Tensile strength (MPa) | 1040 ±20 |
|---|---|
| Hardness | 29 ±3 HRC |
| Thermal conductivity (W/m·K) | 9.8 (21 °C) |
| Elongation (%) | 22 ±2 |
| Yield strength (MPa) | 770 ±30 |
Solid-part reference values from the cited datasheet; not a powder or batch guarantee. Source: 3D Systems · LaserForm Ni625(A), 2017, p.1 ↗
Powder properties
| Particle size cut | 15–53 µm |
|---|---|
| Flow time | ≤ 20 s/50 g |
| Apparent density | ≥ 3.5 g/cm³ |
| Tap density | ≥ 4.0 g/cm³ |
Source: CNPC POWDER Company Catalog. Catalog data is a reference for material selection; the datasheet, certificate of analysis and application tests of the delivered batch prevail.
Particle size and compatible processes
The standard cut is 15–53 µm, suitable for laser powder bed fusion (LPBF / SLM / DMLS) machines. Coarser cuts for DED/LMD processes can be requested. Share your machine model and layer thickness and we will confirm the right cut and batch documents together.
Frequently asked questions
Where is Inconel 625 preferred?
In seawater, acidic and chloride environments, and where high-temperature oxidation occurs together with corrosion.
Inconel® 625 powder price: what does it depend on?
The price depends on order quantity (kg), particle size cut, packaging (argon-filled cans or bottles), required documents (certificate of analysis, PSD report) and lead time. For a current price, state the quantity and your machine model in the quote form.
Which documents come with the order?
A certificate of analysis with chemical composition, particle size distribution (D10/D50/D90), flow and density values can be requested for each batch. Additional documents for aerospace, medical or dental projects are confirmed at the quotation stage.
Price and supply
Send your price and delivery request for Inconel® 625 powder with quantity, particle size, machine model and required quality documents. Supply options and documents are confirmed with the quotation.
Verify medium chemistry, temperature, welding/repair needs and the current certificate of analysis.
