In short: Scalmalloy® is an aluminium-magnesium-scandium-zirconium alloy developed for additive manufacturing. It offers significantly higher strength and ductility than conventional AlSi10Mg and is used where weight is critical in aerospace, space and motorsport.
Typical applications
- Aerospace and space structural parts
- Motorsport and high-performance vehicle parts
- Topology-optimised lightweight brackets
Reference properties of printed parts
| Tensile strength (MPa) | 545 |
|---|---|
| Hardness | 170 HV10 |
| Thermal conductivity (W/m·K) | — |
| Elongation (%) | 13 |
| Yield strength (MPa) | 540 |
Solid-part reference values from the cited datasheet; not a powder or batch guarantee. Source: Nikon SLM Solutions · Scalmalloy, 11/2024, p.4–5 ↗
Powder properties
| Particle size cut | 20–63 µm |
|---|---|
| Flow time | ≤ 75 s/50 g |
| Apparent density | ≥ 1.1 g/cm³ |
| Tap density | ≥ 1.3 g/cm³ |
Source: CNPC POWDER Company Catalog. Catalog data is a reference for material selection; the datasheet, certificate of analysis and application tests of the delivered batch prevail.
Particle size and compatible processes
The standard cut is 15–53 µm, suitable for laser powder bed fusion (LPBF / SLM / DMLS) machines. Coarser cuts for DED/LMD processes can be requested. Share your machine model and layer thickness and we will confirm the right cut and batch documents together.
Frequently asked questions
Why is Scalmalloy stronger than AlSi10Mg?
Scandium and zirconium create a fine-grained structure and nano-scale precipitates during ageing, which increase strength. Scalmalloy is therefore sometimes considered a lightweight alternative to titanium.
Scalmalloy® powder price: what does it depend on?
The price depends on order quantity (kg), particle size cut, packaging (argon-filled cans or bottles), required documents (certificate of analysis, PSD report) and lead time. For a current price, state the quantity and your machine model in the quote form.
Which documents come with the order?
A certificate of analysis with chemical composition, particle size distribution (D10/D50/D90), flow and density values can be requested for each batch. Additional documents for aerospace, medical or dental projects are confirmed at the quotation stage.
Price and supply
Send your price and delivery request for Scalmalloy® powder with quantity, particle size, machine model and required quality documents. Supply options and documents are confirmed with the quotation.
State heat treatment and part orientation. Scalmalloy is a registered trademark of APWORKS GmbH; this page is not a statement of authorised reseller status.
